S1160 VALVE STEM VALVE STYLE ON-OFF
FOR VALVE MODEL: 1223H8L RF, STEM PIN
ORBIT COOPER CAMERON VALVES

ACTUATOR REPAIR KIT FOR MODEL# 9600618R001
APPLICATION POWERRAC DOUBLE ACTING CYLINDER ACTUATOR
CONSISTING OF:
(1) SEAL O-RING, P/N 1197212, POS. B10 : QTY.1 EA
(2) COVER GASKET R2, P/N 1197212, POS.B13: QTY. 1 EA
(3) GSKT END COVER,P/N 1214075, POS. B16 : QTY. 2 EA
(4) GASKET BRKT P/N 1250026, POS. B28 : QTY.1 EA
(5) SEAL O-RING, P/N 1083667, POS. B9C : QTY. 1 EA
DEZURIK

369 EPDM ORING 30" - 36" UPPER EXTNSION
T2401303 - 0SKAL00SA
CLOW

O-RING SET
* 12 (O-RING #369-1NO)
* 15 (O-RING #371-1 NO)
* 17 (O-RING#352-1NO)
* 19 (O-RING#236-4NO)
* 21 (O-RING COVER OUTER-1 NO);
* 25 (O-RING#348-1NO) &
* 31 (O-RING COVER INNER-1NO);
O-RING MATERIAL BUNA N RUBBER;
FOR GATE VALVE SIZE: 30 INCH,
MNFR: KENNEDY VALVE COMPANY
DRAWING: LRW 50/51/52/53
REV: 0 ITEM: 12, 15, 17, 19, 21, 25, 31
MATL BUNA/RUBBER
KENNEDY VALVE CO

IA-KV8010 PACKING
PTFE TYPE RING
DWG 70308M02 POS 52 REV 0
FOR TAG/EQUIP NO 14-HV-4107
EQUIP/TAG MODEL NO 6X1233HL RF
ORBIT COOPER CAMERON
